一．用途:

本機采用氣缸送罐及定位，對大小各異、各種形狀的包裝罐封口。該設備大大減輕了勞動強度，操作起來簡單、方便、省力。是制罐行業的理想設備。

二．主要技術參數：

1.生產能力: 12-16罐/分鐘(視操作熟練程度)

2.適用罐型范圍: 對角線50-330毫米

罐高: 50-400毫米

制罐鐵皮厚度:  ≤0.4毫米

3.氣路系統壓力： 0.4-0.7MPa

4．電機: Y112M-6   2.2kw    940轉/分鐘

5.外形尺寸: 980×580×1900毫米(長×寬×高)

6.重量: 800kg

1.Function:

   This can seamer is mainly used to seal round and square can in the industries,such as Food,medicine,chemical,paint,oil and so on.

   It apply four rollers,be with high capacity,low noise,good overlapping rate.The cylinder raise worktable,so as to relieve worker and be more convenient to operate.

2、Parameter：

        Capacity：12-16cpm

        Diameter：50-330mm

        Height:50-400mm

        Tinplate Thickness: ≤0.4mm

        Air pressure：0.4-0.7MPA

        Motor type: Y112M-6

        Revolution speed: 940r/min

        Power： 2.2KW

        Size: 980×580×1900mm

        Weight： 800kg
